120-Gallon Two Stage Electric Duplex – ACD-23175-120H comes complete to meet the most demanding industrial applications

Loaded with standard features, the M Series air compressors are available in many motor configurations. Offered with vertical or horizontal tank options, this series comes complete to meet the most demanding industrial applications.

Compressor Pump:Splash lubricated Stainless steel braided discharge hose Large canister intake filter Oil lever sight indicator

Motor:Industrial low RPM motor Magnetic start for thermal overload protection

Frame:Powder coated ASME coded 120-gallon receiver tank 3/16-inch base plate to reduce vibration Totally enclosed powder coated belt guard

Components:ASME safety valves Tank pressure gauge Hour meter Large fly wheel Intake filter/silencer Tank shut-off valve 3 position switch – compressor 1 (lead motor pump), automatic alternating and compressor 2 (lead motor pump)

Other Models Available:
ACD-20305-120HM200V, 32.2A, 3 Phase
ACD-23305-120HM230V, 27.6A, 3 Phase
ACD-46305-120HM460V, 13.8A, 3 Phase

Specifications

• CFM @ 175

  36.0

• Horsepower/Motor

  5.0 HP, 230V, 1, 46.0A

• Pump RPM

  860

• Compressor

  Two Stage, Cast Iron

• Tank Size

  120 gallon

• Bolt Down (LxW)

  34.5 x 23.5 in.

Weights & Dimensions

• Net Weight

  871.00 lbs.

• Shipping Weight

  950.00 lbs.

• Length

  74.00 in.

• Width

  26.50 in.

• Height

  58.00 in.
